When choosing a hydraulic hose fitting, it's important to consider the size, material, temperature, and pressure. A wrong choice can lead to leaks and loss of pressure in the system which could pose a safety threat.
Most fittings are either all-metal or flanged. All-metal fittings create a seal by using stress to force the threads together.
Size
One of the most common problems in hydraulic systems occurs when a fitting is mismatched to the hose. It may result in leaks and even fire, posing a serious safety risk. To prevent this, always use a thread pitch gauge to verify the fitting's size and match it with the correct hose.
Ensure the hose's dash size matches the fitting's nominal size, which is shown on the fitting and written as a number followed by "-", or one-sixteenth of an inch. Refer to the manufacturer's specifications or consult with a hydraulic professional to determine the optimum hose size for a given application, including the desired flow rate and pressure.
Also consider whether you're using a reusable or permanent fitting. Reusable fittings are easily identifiable and can be removed with a wrench, while permanent crimped fittings require a specialized tool to remove. Stainless steel fittings offer the highest level of corrosion resistance, but they're typically more expensive than other types of fittings.
Material
Choosing the right fitting for hydraulic hoses is essential for preventing leaks, which can be hazardous and even dangerous to humans. To avoid costly repairs, it`s important to choose fittings that are compatible with the hoses they are connected to. This will help prevent the occurrence of explosions, fires, or toxic fumes.
The type of material used for hydraulic hose fittings is also important. Most fittings are made of stainless steel, which is suitable for most applications, but other materials can be used in specific situations. It`s essential to select the type of material that is compatible with the hose and will withstand the pressure applied.
Another factor to consider is the temperature. The hose should be rated for the operating environment, which includes the average, minimum and maximum temperatures. This will help to reduce maintenance costs and downtime. If the hose is not properly rated, it can lead to damage and reduced system life.
Temperature
The temperature of the fitting is important to consider because it can affect how long the hose will last. Exposure to temperatures above the maximum rated temperature can cause the fluid within the hose to deteriorate and cause the hose to fail.
All hoses have a maximum rated media temperature and it is important to keep the fluid in your hydraulic system below that level. Also, if you need to use a hose in cold temperatures, make sure you choose one that is designed for low temperatures and has gone through rigorous testing by the hose manufacturer.
The pressure of the hose or tubing is another factor that must be considered when selecting a hose fitting. Like hoses, tube fittings are rated with specific pressures depending on their size, material and end configuration. It is important to compare the hose or tubing`s pressure rating with the pressure rating of the hose fittings to ensure they are compatible.
Pressure
If a fitting is incorrectly sized it may not seal properly or cause a leak. Using the right tool to crimp the fitting and correctly following hose manufacturer's crimp specifications will ensure the assembly is safe and effective.
When choosing a hydraulic hose fitting consider the maximum and minimum values it can handle as well as where it will be used. If it will be exposed to vibration, unusual mechanical loads or extreme temperatures then choose a higher strength and durability fitting.
Hydraulic hose fittings can be all-metal or O-ring sealed and come in different shapes, sizes and configurations. A flanged fitting for example forms a seal against pressurized fluid through metal-to-metal contact, while an O-ring hydraulic hose coupling uses stress to trap the O-ring and create a leak-proof connection. Also, there are reusable hydraulic hose fittings and permanent/crimped (also known as pinned or threaded) fittings. Reusable fittings can be removed and replaced manually, whereas a permanent/crimped fitting must be secured with a crimper to connect to the hose.
